Static Scissor Tables

WARRIOR Static Lift Tables

Low Profile Lift Tables achieve a low closed height and usually eliminate the need for a pit
They lift up to around 860mm and also help alleviate bending and twisting often found in industrial environments
Tables are controlled by a 24V "satellite" hydraulic power pack consisting of an Up, Down and Emergency Stop buttons
Tables are powered by AC380v / 50Hz / 3 phase mains
Pressure relief valve fitted to protect the hydraulic system
Oil less bushing on axle pivots
Emergency check valve to ensure slow controlled descent in the event of a hydraulic line failure
Removable lifting eyes to facilitate easy handling and installation
Tables have fully interlocked descent arrestors should there be an obstruction
These tables are manufactured to EN1570:1999 and are IP54 protected
Available in two standard capacities 1000Kg & 1500kg the units have both Full Top and U shape derivatives

WARRIOR Lift Tables can be used either at ground level or in a pit
They lift up to 1050mm and also help alleviate bending and twisting often found in industrial environments
Tables are controlled by a 24V "inbuilt" hydraulic power pack consisting of an Up and Down pendent
Tables are powered by AC380v / 50Hz / 3 phase mains
Pressure relief valve fitted to protect the hydraulic system
Oilite bushing on axle pivots
Emergency check valve to ensure slow controlled descent in the event of a hydraulic line failure
Removable lifting eyes to facilitate easy handling and installation
Tables have fully interlocked descent arrestors should there be an obstruction
These tables are manufactured to EN1570:1999 and are IP54 protected
Available ex stock in one standard capacity 2000Kg
Other models available or request
