Static Scissor Tables


WARRIOR Static Lift Tables

  • Low Profile Lift Tables achieve a low closed height and usually eliminate the need for a pit
  • They lift up to around 860mm and also help alleviate bending and twisting often found in industrial environments
  • Tables are controlled by a 24V “satellite” hydraulic power pack consisting of an Up, Down and Emergency Stop buttons
  • Tables are powered by AC380v / 50Hz / 3 phase mains
  • Pressure relief valve fitted to protect the hydraulic system
  • Oil less bushing on axle pivots
  • Emergency check valve to ensure slow controlled descent in the event of a hydraulic line failure
  • Removable lifting eyes to facilitate easy handling and installation
  • Tables have fully interlocked descent arrestors should there be an obstruction
  • These tables are manufactured to EN1570:1999 and are IP54 protected
  • Available in two standard capacities 1000Kg & 1500kg the units have both Full Top and U shape derivatives
Model HY1001 HU1000 HY1501 HU1500
Capacity 1000 1000 1500 1500
Maximum Height (mm) 860 860 880 860
Minimum Height (mm) 85 85 105 105
Platform (LxW) (mm) 1450×1140 1450×1140 1600×800 1600×1180
Lifting Cycle (sec) 20 18 20 18
Stroke (mm) 775 775 775 775
Power Pack Kw 0.75 0.75 1.5 1.5
Nett Weight (Kg) 357 280 362 380


WARRIOR Static Lift Tables

Model HD1001 HD2002 HD2000
Capacity 1000 2000 2000
Max Height (mm) 1000 1050 1780
Min Height (mm) 205 230 360
Platform (L X W) (mm) 1300 x 820 1600 x 1000 1300 x 850
Lifting Cycle (sec 20 20 40
Power pack (Kw) 1.1 1.5 2.2
Net Weight (Kg) 160 268 295


  • WARRIOR Lift Tables can be used either at ground level or in a pit
  • They lift up to 1050mm and also help alleviate bending and twisting often found in industrial environments
  • Tables are controlled by a 24V “inbuilt” hydraulic power pack consisting of an Up and Down pendent
  • Tables are powered by AC380v / 50Hz / 3 phase mains
  • Pressure relief valve fitted to protect the hydraulic system
  • Oilite bushing on axle pivots
  • Emergency check valve to ensure slow controlled descent in the event of a hydraulic line failure
  • Removable lifting eyes to facilitate easy handling and installation
  • Tables have fully interlocked descent arrestors should there be an obstruction
  • These tables are manufactured to EN1570:1999 and are IP54 protected
  • Available ex stock in one standard capacity 2000Kg
  • Other models available or request
