TRACTIVE PUSHER TP250

UP TO 5000KG – TRACTIVE PUSHER TP250

Our TP250 Tractive pusher is pedestrian operated and battery powered, designed to push, pull and manoeuvre wheeled loads. Used in rail applications this Tractive unit will move 25,000kg and move 5000kg on trolleys. They ensure that operators can enjoy safe and efficient handling at all times. Simple to use, robust and ergonomically designed, we believe our Tractive unit to be the best on the Market!

Our powerful pedestrian pusher will be adapted by our expert in house design team to move almost any wheeled load. Market sectors our electric tow tugs include, pharmaceuticals, textiles, aerospace, automotive, rail industry, retail, airport, manufacturing and construction.



tp250-2 tp250-1

tp250-3



Technical Specifications:

Draw Bar Pull 2500N
Towing Capacity on Rails 25000kg
Towing Capacity on Castors 5000kg
Drive System AC Control
Motor Power 1000W
Controller Current 200A
Battery Capacity 70A/h
Max Speed 6kph
Turning Circle 1.5m
